| Properties | BFD30-30 | BFD40-40 | BFD50-50 | BFD80-80 | BFD100-100 | BFD125-125 | BFD150-150 | |
| Size of mesh mm | 12.7×12.7 | 25.4×25.4 | 50.8×50.8 | |||||
| Tensile Strength kN/m | Longitudinal | ≥30 | ≥40 | ≥50 | ≥80 | ≥100 | ≥125 | ≥150 |
| Transverse | ≥30 | ≥40 | ≥50 | ≥80 | ≥100 | ≥125 | ≥150 | |
| Elongation Rate % | ≤4 | |||||||
| Temperature Resistance ℃ | -100-280 | |||||||
This material is composed of high-strength glass fiber yarns coated with polymers (e.g., PVC, latex, or asphalt), forming a durable grid-like mesh with uniform apertures for optimal soil/aggregate interlocking. Key features include high tensile strength (50–400 kN/m), corrosion resistance, thermal stability (-70°C to 200°C), and lightweight flexibility, making it ideal for soil reinforcement, erosion control, and infrastructure projects.
– Brief Introduction
1. Material & Structure
Composition: Made from high-strength glass fiber yarns coated with polymer (e.g., PVC, latex, or asphalt) for enhanced durability.
Structure: Grid-like mesh formed by weaving or knitting fibers, with uniform apertures for optimal interlocking with soil/aggregate.
2. Key Features
High Tensile Strength: Resists deformation under heavy loads (e.g., 50–400 kN/m tensile strength).
Corrosion Resistance: Inert to chemicals, moisture, and biological degradation.
Thermal Stability: Maintains performance in extreme temperatures (-70°C to 200°C).
Lightweight & Flexible: Easy to transport and install on uneven surfaces.
